Extruded tube
The extruded tube
What is an extruded tube ?
Monolayer tube in Polyethylene which can be made in different densities :
It is a single layer extruded pipe, made of Polyethylene (PE) of different densities:
Low Density PE (LDPE) = flexible and average resistance to chemical aggression.
Mixed Low Density and High Density PE (PEMixBDHD) = semi rigid and good resistance to chemical aggression.
The High Density PE (HDPE) = rigid and strong resistance to chemical aggressions
Printing on a formed tube.
Technical informations of the extruded tube
In order to familiarize with the terms linked to flexible plastic tubes and printing, you will find here a lexical.
Tubes are packaged head first, in a cardboard box (with or withour plastic cover). 4 boxes per layer on wooden palett 80cmx120cm. Quantity per box according to tube diameter :
383 tubes
259 tubes
192 tubes
140 tubes
88 tubes
En bref sur le tube extrudé
The extruded tube meets your expectations if you are looking for plastic packaging, printed in classic or complex offset printing up to 6 colors.
This packaging is dedicated to cosmetics as well as food, industrial and DIY products, with its wide range of diameters, from D25 to D50.
Diameters of extruded tubes
D25
- Capacity from 10 to 50 ml
- Offset printing - Hot Stamping
- Perfo 1,5-2,5 mm
- Available caps : screw cap
D25 CANULA
- Offset printing - Hot Stamping
- Perfo 1,5mm
- Available caps : screw caps canula D25/D19
D30
- Capacity from 25 to 75 ml
- Offset printing - Hot Stamping
- Perfo 2/3/5 mm
- Available caps : screw cap - snap-on flip top cap
D35
- Capacity from 40 to 125ml
- Offset printing – Silkscreen printing - Hot Stamping
- Perfo 2/3/5/8 mm
- Available caps : screw cap / snap-on or screw on flip top cap
D40
- Capacity from 50 to 200ml
- Offset printing – Silkscreen printing - Hot Stamping
- Perfo 2/3/5/8 mm
- Available caps : screw cap - snap on flip top cap - temper evident flip top cap - screw-on flip top cap
D50
- Capacity from 100 to 300ml
- Offset printing– Silkscreen printing - Hot Stamping
- Perfo 2/3/5/8 mm
- Available caps : screw cap - snap-on flip top cap - temper evident flip top cap - screw-on flip top cap
TUBE EXTRUDÉ D50 CANULE
- Capacity from 100 to 300ml
- Offset printing– Silkscreen printing - Hot Stamping
- Canula Neck
- Avaimable cap : striated screw cap
Extruded tubes - screw caps
Standard - DJL
∅25 : ∅24 x height 12,8
∅30 : ∅29 x height 15
∅35 : ∅34 x height 16
∅40 : ∅38 x height 19,6
∅50 : ∅47,1 x height 26
Color : White
Aspect : Shiny
Option metallised gold / silver
Other color / aspect : contact us
Softline deluxe - SFD
∅25 : ∅23,5 x height 20
∅30 : ∅29,1 x height 22
∅35 : ∅34,1 x height 23
Color : White
Aspect : Shiny
Option metallised gold / silver
Other diameter / color / aspect : contact us
Hardline deluxe - HRD
∅25 : ∅23,5 x height 20
∅30 : ∅29,1 x height 22
∅35 : ∅34 x height 23
Color : White
Aspect : Brillant
Option metallised gold / silver
Other diameter / color / aspect : contact us
Striated - DJS
∅50 : ∅48 x height 26
Other diameter / color : contact us
Extruded tubes - flip top caps
Flip top cap - ZP
∅30 : ∅29 x height 22
Perfo : 3
Color : White
Aspect : Shiny or matt
Other diameters / colors : contact us
Screw-on flip top cap - MA
∅35 : ∅34 x height 21,7
∅40 : ∅38 x height 21,7
∅50 : ∅48 x height 24,7
Perfo : 5
Color : White
Aspect : Shiny or matt
Other diameters / colors : contact us
Snap-on flip top cap - KM
∅50 : ∅48 x height 24,7
∅40 : ∅38 x height 21,7
∅35 : ∅38 x height 21,7
Perfo : 2,3,5 (according to diameter)
Color : White
Aspect : Shiny or matt
Other perfo / colors : contact us
Temper evident fliptop cap - KMi
∅50 : ∅48 x height 24,7
∅40 : ∅38 x height 21,7
Perfo : 3 et 5
Color : White
Aspect : Shiny
Other colors : contact us
Extruded tubes - Others caps
Twist cap - ST
∅35 : ∅33,5 x height 22,8
∅40 : ∅39,1 x height 24,3
Color : White / black
Others colors : contact us
Twist canula
∅35/35/40 : ∅31,6 x height 38,9
Color : White / translucent
Sponge applicator
∅35 : ∅34,6 x height 26
Translucent cap
